Subwoofer Hertz ES200 400w

Descriptions

ES200 Subwoofer 200 mm 4Ω per utilizzo in cassa I subwoofer Energy sono stati progettati per esprimere il massimo delle prestazioni in box di ridotto litraggio. I loro parametri elettroacustici sono ottimizzati per un corretto funzionamento in qualsiasi tipo di cassa (sospensione pneumatica, bass reflex, passabanda, etc), assicurando una straordinaria versatilità e prestazioni di altissima qualità. Limpiego di un equipaggio mobile a lunga escursione e del doppio magnete ad alta intensità di flusso ha consentito di realizzare componenti in grado di sopportare elevate potenze, con una straordinaria musicalità unita ad una dinamica esplosiva. Le finiture in vernice antigraffio e un anello in gomma butilica offrono protezione affidabile assieme ad un look moderno e aggressivo. Size mm 200 (8”) Power peak 400 Handling continuous program 200 (Watt) Impedance Ohm 4 Frequency Hz 30 - 400 response Sensitivity dB/SPL 87 Outer mm 216 diameter Mounting mm 181 hole diameter Magnet size mm 120 Total depth mm 121 Mounting mm 106 depth Total driver lit 0,9 displacement Weight of one Kg 3,680 component Voice mm 50 coil diameter Magnet Double magnet, High density flux ferrite Cone Water repellent, pressed paper cone Xmech* mm 14,5 High thermal dissipation and magnetic permeability plates, providing constant, even flux. Large double magnet, for perfect control under high power, high excursion conditions. Copper voice coil, wound on aluminium former, for startling thermal and mechanical capacity. Back plate vent holes, for very good thermal dissipation. Back Vented Spider support, for perfect symmetry under high excursion and thermal dissipation. Butyl rubber gasket provides ideal coupling to the mounting surface, damping basket resonance. Butyl rubber magnet ring provides protection against abrasions. Internally reinforced basket, protected from abrasions by high resistance paint. High current, tin-plated terminals. Silver plated silicone shielded lead wires for maximum reliability and conductivity. Basket and motor coupled and damped through special epoxy glue. Wide-wave, resin-bonded fibre spider for mechanical reliability and consistent parameters. High density Foam surround, for linear movement even under high excursion conditions. Water-repellent pressed paper cone.
